Image preview - the first page of the document
MSA5TCD00L18145


>> Download MSA5TCD00L18145 documenatation <<

Text preview - extract from the document
                         LEGACY (W2260BE_SGML Complete)



2-3      [M700]                  MECHANISM AND FUNCTION
7. Cylinder Head


7. Cylinder Head
D The cylinder head is made from aluminium die casting.
D Combustion chamber in the cylinder head is a compact, pentroof design and spark plug is lo-
cated at the center of combustion chamber which feature a wide "squish" area for increased com-
bustion efficiency.
D Four valves (two intake and two exhaust), which are arranged in a cross-flow design, are used
per cylinder.
D The cylinder head gasket is a metallic one consisting of three layers of the stainless steel sheets.
It has better heat resistance and gas sealability and higher reliability.




                                                                                             B2H3341A

      (1) Intake valve                                    (5) Exhaust port
      (2) Intake port                                     (6) Exhaust valve
      (3) Squish area                                     (7) Spark plug
      (4) Combustion chamber
