Image preview - the first page of the document
MSA5TCD00L18147


>> Download MSA5TCD00L18147 documenatation <<

Text preview - extract from the document
                     LEGACY (W2260BE_SGML Complete)



2-3     [M900]                 MECHANISM AND FUNCTION
9. Crankshaft


9. Crankshaft
The crankshaft is supported by five bearings to provide high rigidity and strength. The corners
of the crankshaft journals and webs, as well as the crank pins and webs, are finished with fillet-roll
work to increase stiffness. The five crankshaft bearings are made from aluminum alloy and the
No. 5 bearing is provided with a flanged metal to receive thrust force.




                                                                                             B2H1978A




                                                 10
