                     LEGACY (W2260BE_SGML Complete)



2-5      [M3A0]               MECHANISM AND FUNCTION
3. Water Pump


3. Water Pump
A: MECHANISM
The water pump is located on the left front portion of the cylinder block and is driven by the timing
belt. The thermostat is built into the engine coolant inlet located on the lower side of the water
pump. When the impeller rotates, engine coolant is drawing into the water pump from the lower
pipe (which is connected to the radiator hose) via the thermostat. It then flows along the perimeter
of the impeller and is delivered to the engine's engine coolant passage.




                                                                                             H2H2324


  (1) Pulley                        (3) Mechanical seal              (5) Thermostat
  (2) Ball bearing                  (4) Impeller                     (6) Thermostat case
