Image preview - the first page of the document
MSA5TCD00L18840


>> Download MSA5TCD00L18840 documenatation <<

Text preview - extract from the document
3-4   [W1A0]                         SERVICE PROCEDURE
1. Propeller Shaft


1. Propeller Shaft                                         4) Turn rear wheels by hand to check for "runout"
                                                           of propeller shaft.
A: ON-CAR SERVICE                                          NOTE:
Check the following points with propeller shaft            Measure runout with a dial gauge at the center of
installed in vehicle.                                      front and rear propeller shaft tubes.
                                                           Runout:
1. JOINTS AND CONNECTIONS                                     Limit 0.6 mm (0.024 in)
1) Remove front and center exhaust pipes.

2) Remove heat shield cover.
3) Check for any looseness of yoke flange con-
necting bolts and center bearing retaining bolts.
2. SPLINES AND BEARING LOCATIONS
1) Remove front and center exhaust pipes.

2) Remove rear exhaust pipe and muffler.
 and                                                   B3M1603A

3) Remove heat shield cover.                                  (A)   Propeller shaft
4) Turn propeller shaft by hand to see if abnormal            (B)   Dial gauge
free play exists at splines. Also move yokes to see
if abnormal free play exists at spiders and bear-          4. CENTER BEARING FREE PLAY
ings.                                                      1) Remove front and center exhaust pipes.

                                                           2) Remove rear exhaust pipe and muffler.
                                                            and
                                                           3) Remove heat shield cover.
                                                           4) While holding propeller shaft near center bear-
                                                           ing with your hand, move it up and down, and left
                                                           and right to check for any abnormal bearing free
                                                           play.


                                        B3M1602



3. RUNOUT OF PROPELLER SHAFT
1) Remove front and center exhaust pipes.

2) Remove rear exhaust pipe and muffler.
 and
3) Remove heat shield cover.                                                                      B3M1604




                                                      10
                                       SERVICE PROCEDURE                                          [W1B0] 3-4
                                                                                               1. Propeller Shaft


B: REMOVAL                                                   8) Remove the four bolts which hold propeller
                                                             shaft to rear differential.
NOTE:
