Image preview - the first page of the document
MSA5TCD00L18817


>> Download MSA5TCD00L18817 documenatation <<

Text preview - extract from the document
                                      SERVICE PROCEDURE                                         [W13C0] 3-2
                                                                             13. Reduction Drive Gear Assembly


13. Reduction Drive Gear                                    3) Attach two seal rings.
Assembly                                                    NOTE:
                                                            To make subsequent assembly easier, apply vase-
A: DISASSEMBLY                                              line to the grooves of the shaft and to the exterior
                                                            of the seal ring.
1) Take out the seal rings.
CAUTION:
Be careful not to damage the seal rings.




                                                                                                    B3M1121A




                                        B3M1121A

2) Using ST, remove the ball bearing.
ST 498077600 REMOVER




                                        B3M0962A

3) Using a press, remove the reduction drive gear.




                                        B3M0963A



B: INSPECTION
Make sure that each component is free of harmful
gouges, cuts, or dust.

C: ASSEMBLY
1) Press-fit the reduction drive gear to the shaft.
2) Press-fit the ball bearing to the reduction drive
gear.

                                                       77
