Image preview - the first page of the document



>> Download repl documenatation <<

Text preview - extract from the document

LU-2
                                    LUBRICATION   -   OIL AND FILTER
                                                                                                        LU02L-03


                                        REPLACEMENT
                                        CAUTION:
                                         S  Prolonged and repeated contact with mineral oil will
                                            result in the removal of natural fats from the skin,
                                            leading to dryness, irritation and dermatitis. In addi-
                                            tion, used engine oil contains potentially harmful
                                            contaminants which may cause skin cancer.
                                         S  Exercise caution in order to minimize the length and
                                            frequency of contact of your skin to used oil. Wear
                                            protective clothing and gloves. Wash your skin thor-
                                            oughly with soap and water, or use water-less hand
                                            cleaner, to remove any used engine oil. Do not use
                                            gasoline, thinners, or solvents.
                                         S  In order to preserve the environment, used oil and
                                            used oil filter must be disposed of only at designated
                                            disposal sites.
                                        1.  DRAIN ENGINE OIL
                                        (a) Remove the oil filter cap.
                                        (b) Remove the oil drain plug, and drain the oil into a contain-
                                            er.
                                        2.  REPLACE OIL FILTER
                                        (a) Using SST, remove the oil filter.
                                            SST 09228-06501
                        SST             (b) Check and clean the oil filter installation surface.
                                        (c) Check the part number of the new oil filter is as same as
                                            old one.
                                        (d) Apply clean engine oil to the gasket of a new oil filter.

                               B09336


                                        (e)   Lightly screw the oil filter into place, and tighten it until the
                  3/4                         gasket contacts the seat.
                 Turn                   (f)   Using SST, tighten it an additional 3/4 turn.
                              SST             SST 09228-06501
                                        3.    REFILL WITH ENGINE OIL
                                        (a)   Clean and install the oil drain plug with a new gasket.
                                              Torque: 38 N
