Image preview - the first page of the document



>> Download cec8218 documenatation <<

Text preview - extract from the document

                                                                                                   CEC8218
Dual N-Channel Enhancement Mode Field Effect Transistor

FEATURES
                                                                                                   D                        D
  20V, 6.5A, RDS(ON) = 23m @VGS = 4.5V.

             RDS(ON) = 34m @VGS = 2.5V.

  Super High dense cell design for extremely low RDS(ON).                           *1K                           *1K
                                                                          G1                           G2

  High power and current handing capability.

  Lead free product is acquired.
                                                                                                 S1                        S2
                                                                               *Typical value by design

                                                                                               D D D D
                                                                                               8     7      6    5

                                                                                                Bottom View



                                                                                               1     2      3    4
                                                        DFN3*3
                                                                                              S1 G S2 G
                                                                                                  1    2



ABSOLUTE MAXIMUM RATINGS                            TA = 25 C unless otherwise noted
                      Parameter                             Symbol                           Limit                          Units
  Drain-Source Voltage                                           VDS                           20                            V
  Gate-Source Voltage                                            VGS
