Image preview - the first page of the document



>> Download ced20p10_ceu20p10 documenatation <<

Text preview - extract from the document

                                                  CED20P10/CEU20P10
P-Channel Enhancement Mode Field Effect Transistor                                                        PRELIMINARY



FEATURES

  -100V, -16A, RDS(ON) = 130m            @VGS = -10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
  Lead-free plating ; RoHS compliant.                                                             D
  TO-251 & TO-252 package.




                                             D                                G

                               G                        G
                                                         D
                                  S                        S
                             CEU SERIES                 CED SERIES
                             TO-252(D-PAK)              TO-251(I-PAK)                             S




ABSOLUTE MAXIMUM RATINGS                                Tc = 25 C unless otherwise noted
                     Parameter                               Symbol                    Limit                   Units
  Drain-Source Voltage                                             VDS                 -100                     V
  Gate-Source Voltage                                              VGS
