Image preview - the first page of the document



>> Download ced30p10_ceu30p10 documenatation <<

Text preview - extract from the document

                                                 CED30P10/CEU30P10
P-Channel Enhancement Mode Field Effect Transistor

FEATURES

  -100V, -30A, RDS(ON) = 76m         @VGS = -10V.

               RDS(ON) = 92m         @VGS = -4.5V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.                                                  D
 Lead free product is acquired.
  TO-251 & TO-252 package.



                                             D                             G

                               G                     G
                                                      D
                                  S                     S
                             CEU SERIES              CED SERIES
                             TO-252(D-PAK)           TO-251(I-PAK)                            S




ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                    Parameter                             Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                -100                   V
  Gate-Source Voltage                                            VGS
