Image preview - the first page of the document



>> Download ced6601_ceu6601 documenatation <<

Text preview - extract from the document

                                                          CED6601/CEU6601
P-Channel Enhancement Mode Field Effect Transistor

FEATURES

  -60V, -16A, RDS(ON) = 86m         @VGS = -10V.
              RDS(ON) = 125m         @VGS = -4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.                                                  D
  Lead free product is acquired.

  TO-251 & TO-252 package.



                                             D                             G

                               G                     G
                                                      D
                                  S                     S
                             CEU SERIES              CED SERIES
                             TO-252(D-PAK)           TO-251(I-PAK)                            S




ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                     Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                 -60                   V
  Gate-Source Voltage                                            VGS
