Image preview - the first page of the document
>> Download cem2182 documenatation <<
Text preview - extract from the document
CEM2182
N-Channel Enhancement Mode Field Effect Transistor PRELIMINARY
FEATURES
20V, 9.3A, RDS(ON) = 18m @VGS = 4.5V.
RDS(ON) = 24m @VGS = 2.5V.
Super high dense cell design for extremely low RDS(ON).
High power and current handing capability.
D D D D
Lead-free plating ; RoHS compliant. 8 7 6 5
Surface mount Package.
SO-8
1 2 3 4
1 S S S G
ABSOLUTE MAXIMUM RATINGS TA = 25 C unless otherwise noted
Parameter Symbol Limit Units
Drain-Source Voltage VDS 20 V
Gate-Source Voltage VGS ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
