Image preview - the first page of the document



>> Download cem4948 documenatation <<

Text preview - extract from the document

                                                                                        CEM4948
Dual P-Channel Enhancement Mode Field Effect Transistor

FEATURES
                                                                                                                            5
  -60V, -3.1A, RDS(ON) = 120m @VGS = -10V.
              RDS(ON) = 150m @VGS = -4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
 Lead free product is acquired.                                                   D1          D1   D2   D2
                                                                                  8           7    6    5
  Surface mount Package.




                                            SO-8
                                                                                   1          2    3    4
                                                            1                      S1         G1   S2   G2




ABSOLUTE MAXIMUM RATINGS                             TA = 25 C unless otherwise noted
                    Parameter                             Symbol                    Limit                      Units
  Drain-Source Voltage                                          VDS                     -60                     V
  Gate-Source Voltage                                           VGS
