Image preview - the first page of the document
>> Download cem4308 documenatation <<
Text preview - extract from the document
CEM4308
Dual N-Channel Enhancement Mode Field Effect Transistor
FEATURES
5
40V, 5.8A, RDS(ON) = 38m @VGS = 10V.
RDS(ON) = 50m @VGS = 4.5V.
Super high dense cell design for extremely low RDS(ON).
High power and current handing capability.
D1 D1 D2 D2
Lead free product is acquired. 8 7 6 5
Surface mount Package.
SO-8 1 2 3 4
1 S1 G1 S2 G2
ABSOLUTE MAXIMUM RATINGS TA = 25 C unless otherwise noted
Parameter Symbol Limit Units
Drain-Source Voltage VDS 40 V
Gate-Source Voltage VGS ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
