Image preview - the first page of the document



>> Download cem6188 documenatation <<

Text preview - extract from the document

                                                                                        CEM6188
Dual N-Channel Enhancement Mode Field Effect Transistor                                                       PRELIMINARY



FEATURES

  60V, 7.3A, RDS(ON) = 26m @VGS = 10V.

             RDS(ON) = 35m @VGS = 4.5V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
                                                                                   D1         D1   D2    D2
  Lead free product is acquired.                                                   8          7    6     5

  Surface mount Package.




                                            SO-8                                   1          2     3    4
                                                            1                      S1         G1    S2   G2




ABSOLUTE MAXIMUM RATINGS                             TA = 25 C unless otherwise noted
                     Parameter                              Symbol                  Limit                        Units
  Drain-Source Voltage                                           VDS                    60                        V
  Gate-Source Voltage                                            VGS
