Image preview - the first page of the document



>> Download cem8311 documenatation <<

Text preview - extract from the document

                                                                                         CEM8311
Dual P-Channel Enhancement Mode Field Effect Transistor

FEATURES
                                                                                                                             5
  -30V, -7.9A, RDS(ON) = 20m @VGS = -10V.
               RDS(ON) = 33m @VGS = -4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.

  Lead free product is acquired.                                                   D1          D1   D2   D2
                                                                                   8           7    6    5
  Surface mount Package.




                                             SO-8
                                                                                    1          2    3    4
                                                            1                       S1         G1   S2   G2




ABSOLUTE MAXIMUM RATINGS                              TA = 25 C unless otherwise noted
                     Parameter                             Symbol                    Limit                      Units
  Drain-Source Voltage                                           VDS                     -30                     V
  Gate-Source Voltage                                            VGS
