Image preview - the first page of the document



>> Download cem9936a documenatation <<

Text preview - extract from the document

                                                                                CEM9936A
Dual N-Channel Enhancement Mode Field Effect Transistor

FEATURES
                                                                                                                            5
  30V, 5.4A, RDS(ON) = 40m @VGS = 10V.
             RDS(ON) = 55m @VGS = 4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.

  Lead free product is acquired.                                                   D1         D1   D2   D2
                                                                                   8          7    6    5
  Surface mount Package.




                                            SO-8
                                                                                   1          2    3    4
                                                            1                      S1         G1   S2   G2




ABSOLUTE MAXIMUM RATINGS                             TA = 25 C unless otherwise noted
                     Parameter                              Symbol                 Limit                       Units
  Drain-Source Voltage                                          VDS                     30                      V
  Gate-Source Voltage                                           VGS
