                                                                                 CEN7002A
N-Channel Enhancement Mode Field Effect Transistor

FEATURES

 60V, 0.25A, RDS(ON) = 3  @VGS = 10V.
             RDS(ON) = 4  @VGS = 4.5V.
 High dense cell design for extremely low RDS(ON).

  Rugged and reliable.                                                                        D
 Lead free product is acquired.

 SOT-23-T package.


                                    CEN7002A
                                    SOT-23-T                                 G
                                                       D
                                                                         S

                                                                     G

                                  Die upside up              SOT-23-T
                                  package.                                                    S



ABSOLUTE MAXIMUM RATINGS                             TA = 25 C unless otherwise noted
                    Parameter                              Symbol                  Limit                  Units
 Drain-Source Voltage                                       VDS                         60                 V
 Gate-Source Voltage                                        VGS
