                                               CEP05P03/CEB05P03
P-Channel Enhancement Mode Field Effect Transistor

FEATURES

 -30V, -18A,RDS(ON) = 70m @VGS = -10V.
             RDS(ON) = 120m @VGS = -4.5V.
 Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
                                                                                             D
 Lead free product is acquired.

 TO-220 & TO-263 package.


                                       D
                                                                          G
                                               G
                             G                 D
                                S               S
                            CEB SERIES              CEP SERIES
                            TO-263(DD-PAK)          TO-220                                   S




ABSOLUTE MAXIMUM RATINGS                            Tc = 25 C unless otherwise noted
                    Parameter                            Symbol                    Limit                 Units
 Drain-Source Voltage                                       VDS                     -30                   V
 Gate-Source Voltage                                        VGS
