                                                 CEP13N10/CEB13N10
N-Channel Enhancement Mode Field Effect Transistor

FEATURES

  100V, 12.8A, RDS(ON) = 180m @VGS = 10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.

  Lead free product is acquired.                                                               D

  TO-220 & TO-263 package.



                                        D
                                                                            G
                                                 G
                              G                  D
                                 S                S
                             CEB SERIES               CEP SERIES
                             TO-263(DD-PAK)           TO-220                                   S



ABSOLUTE MAXIMUM RATINGS                              Tc = 25 C unless otherwise noted
                      Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                 100                    V
  Gate-Source Voltage                                            VGS
