                                       CEP30N15L/CEB30N15L
N-Channel Enhancement Mode Field Effect Transistor

FEATURES

  150V, 30A, RDS(ON) = 70m @VGS = 10V.
              RDS(ON) = 80m @VGS = 5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
                                                                                               D
  Lead free product is acquired.
  TO-220 & TO-263 package.


                                       D
                                                                            G
                                                 G
                             G                   D
                                S                 S
                            CEB SERIES                CEP SERIES
                            TO-263(DD-PAK)            TO-220
                                                                                               S


ABSOLUTE MAXIMUM RATINGS                              Tc = 25 C unless otherwise noted
                      Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                 150                    V
  Gate-Source Voltage                                            VGS
