Image preview - the first page of the document



>> Download cep540n_ceb540n_cef540n documenatation <<

Text preview - extract from the document

                                                         CEP540N/CEB540N
                                                                 CEF540N
N-Channel Enhancement Mode Field Effect Transistor

FEATURES

  100V, 36A, RDS(ON) = 53m @VGS = 10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.

  Lead free product is acquired.                                                                 D

  TO-220 & TO-263 package.




                      D
                                                                                G
                                   G                 G
            G                      D                     D
              S                     S                        S
          CEB SERIES                    CEP SERIES               CEF SERIES
          TO-263(DD-PAK)                TO-220                   TO-220F                         S



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                      Parameter                           Symbol                    Limit                    Units
  Drain-Source Voltage                                                 VDS             100                    V
  Gate-Source Voltage                                                  VGS
