Image preview - the first page of the document



>> Download cep6042_ceb6042 documenatation <<

Text preview - extract from the document

                                                        CEP6042/CEB6042
N-Channel Enhancement Mode Field Effect Transistor                                                   PRELIMINARY



FEATURES

  60V, 118A, RDS(ON) = 5m @VGS = 10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
                                                                                              D
  Lead-free plating ; RoHS compliant.

  TO-220 & TO-263 package.



                                        D
                                                                           G
                                                G
                             G                  D
                                S                S
                            CEB SERIES               CEP SERIES
                            TO-263(DD-PAK)           TO-220                                   S



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                     Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                 60                    V
  Gate-Source Voltage                                            VGS
