Image preview - the first page of the document



>> Download cep6086l_ceb6086l documenatation <<

Text preview - extract from the document

                                               CEP6086L/CEB6086L
N-Channel Enhancement Mode Field Effect Transistor                                                   PRELIMINARY



FEATURES

  60V, 72A, RDS(ON) = 10m        @VGS = 10V.

            RDS(ON) = 13.5m @VGS = 4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.                                                  D

  Lead-free plating ; RoHS compliant.

  TO-220 & TO-263 package.

                                        D
                                                                           G
                                                G
                             G                  D
                                S                S
                            CEB SERIES               CEP SERIES
                            TO-263(DD-PAK)           TO-220                                   S



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise notedz
                     Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                 60                    V
  Gate-Source Voltage                                            VGS
