Image preview - the first page of the document



>> Download cep740a_ceb740a_cef740a documenatation <<

Text preview - extract from the document

                                                     CEP740A/CEB740A
                                                             CEF740A
N-Channel Enhancement Mode Field Effect Transistor

FEATURES
        Type        VDSS     RDS(ON)       ID     @VGS
   CEP740A          400V      0.55        10A     10V
   CEB740A          400V      0.55        10A     10V
   CEF740A          400V      0.55        10A d   10V


  Super high dense cell design for extremely low RDS(ON).                                                D
  High power and current handing capability.
  Lead-free plating ; RoHS compliant.



               D                                                                  G


                               G                         G
    G                          D                             D
       S                        S                                S                                        S
   CEB SERIES                       CEP SERIES                       CEF SERIES
   TO-263(DD-PAK)                   TO-220                           TO-220F



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                                                                                    Limit
                      Parameter                           Symbol                                                    Units
                                                                           TO-220/263                TO-220F
  Drain-Source Voltage                                               VDS                      400                     V
  Gate-Source Voltage                                                VGS
