Image preview - the first page of the document



>> Download cep95p04_ceb95p04 documenatation <<

Text preview - extract from the document

                                               CEP95P04/CEB95P04
P-Channel Enhancement Mode Field Effect Transistor                                                   PRELIMINARY



FEATURES

  -40V, -93A, RDS(ON) =8.4m @VGS = -10V.
              RDS(ON) =12m @VGS = -4.5V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.                                                  D

  Lead free product is acquired.

  TO-220 & TO-263 package.

                                       D
                                                                          G
                                                G
                             G                  D
                               S                 S
                           CEB SERIES                CEP SERIES
                           TO-263(DD-PAK)            TO-220                                   S



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                     Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                 -40                   V
  Gate-Source Voltage                                            VGS
