Image preview - the first page of the document



>> Download ces2309 documenatation <<

Text preview - extract from the document

                                                                                          CES2309
P-Channel Enhancement Mode Field Effect Transistor                                                    PRELIMINARY



FEATURES

  -20V, -2.2A, RDS(ON) = 165m @VGS = -4.5V.
              RDS(ON) = 300m @VGS = -2.5V.
  High dense cell design for extremely low RDS(ON).

  Rugged and reliable.
                                                                                               D
  Lead free product is acquired.

  SOT-23 package.



                                                                            G
                                                 D
                                                                 S

                                                            G

                                                        SOT-23                                 S




ABSOLUTE MAXIMUM RATINGS                              TA = 25 C unless otherwise noted
                     Parameter                             Symbol                   Limit                  Units
  Drain-Source Voltage                                       VDS                         -20                V
  Gate-Source Voltage                                        VGS
