                                     CED02N65A/CEU02N65A
N-Channel Enhancement Mode Field Effect Transistor                                                   PRELIMINARY



FEATURES

  650V, 1.2A, RDS(ON) = 10.5 @VGS = 10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.
                                                                                              D
  Lead free product is acquired.

  TO-251 & TO-252 package.




                                            D                              G

                              G                      G
                                                      D
                                 S                     S
                            CEU SERIES              CED SERIES
                            TO-252(D-PAK)           TO-251(I-PAK)
                                                                                              S



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                     Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                650                    V
  Gate-Source Voltage                                            VGS
