Image preview - the first page of the document



>> Download ceu4204_ced4204 documenatation <<

Text preview - extract from the document

                                                           CED4204/CEU4204
N-Channel Enhancement Mode Field Effect Transistor

FEATURES

  40V, 24A, RDS(ON) = 28m @VGS = 10V.
             RDS(ON) = 42m @VGS = 4.5V.
  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.                                                   D
  Lead free product is acquired.

  TO-251 & TO-252 package.



                                             D                              G

                               G                      G
                                                       D
                                  S                      S
                             CEU SERIES               CED SERIES
                             TO-252(D-PAK)            TO-251(I-PAK)                            S




ABSOLUTE MAXIMUM RATINGS                              Tc = 25 C unless otherwise noted
                     Parameter                             Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                  40                    V
  Gate-Source Voltage                                            VGS
