                                                     CED740A/CEU740A
N-Channel Enhancement Mode Field Effect Transistor                                                   PRELIMINARY



FEATURES

  400V, 9A, RDS(ON) = 0.55 @VGS = 10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.

  Lead-free plating ; RoHS compliant.
                                                                                              D
  TO-251 & TO-252 package.




                                            D
                                                                           G
                              G                      G
                                                      D
                                 S                     S
                            CEU SERIES              CED SERIES
                            TO-252(D-PAK)           TO-251(I-PAK)
                                                                                              S



ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                     Parameter                            Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                400                    V
  Gate-Source Voltage                                            VGS
