Image preview - the first page of the document



>> Download ceuf640_cedf640 documenatation <<

Text preview - extract from the document

                                                       CEDF640/CEUF640
N-Channel Enhancement Mode Field Effect Transistor

FEATURES

  200V, 15A, RDS(ON) = 0.15  @VGS = 10V.

  Super high dense cell design for extremely low RDS(ON).

  High power and current handing capability.

 Lead free product is acquired.                                                               D

  TO-251 & TO-252 package.




                                             D                             G

                               G                    G
                                                     D
                                  S                    S
                             CEU SERIES             CED SERIES
                             TO-252(D-PAK)          TO-251(I-PAK)                             S




ABSOLUTE MAXIMUM RATINGS                             Tc = 25 C unless otherwise noted
                    Parameter                             Symbol                    Limit                 Units
  Drain-Source Voltage                                           VDS                200                    V
  Gate-Source Voltage                                            VGS
