Image preview - the first page of the document



>> Download cmpt3904e_cmpt3906e documenatation <<

Text preview - extract from the document

               CMPT3904E NPN
               CMPT3906E PNP
                                                                                 w w w. c e n t r a l s e m i . c o m
     ENHANCED SPECIFICATION
   SURFACE MOUNT COMPLEMENTARY                 DESCRIPTION:
        SILICON TRANSISTORS                    The CENTRAL SEMICONDUCTOR CMPT3904E and
                                               CMPT3906E are Enhanced versions of the CMPT3904
                                               and CMPT3906 complementary switching transistors in
                                               a SOT-23 surface mount package, designed for small
                                               signal switching applications, interface circuit & driver
                                               circuit applications.
                                               ENHANCED SPECIFICATIONS:
                                                BVCBO from 40V min to 60V min. (CMPT3906E)
                                                BVEBO from 5.0V min to 6.0V min. (CMPT3906E)
                  SOT-23 CASE                   VCE(SAT) from 0.3V max to 0.2V max. (CMPT3904E)
                                                           from 0.4V max to 0.2V max. (CMPT3906E)
  MARKING CODE: CMPT3904E: C1AE                 hFE from 60 min to 70 min. (CMPT3904E) (CMPT3906E)
                CMPT3906E: C2AE

  MAXIMUM RATINGS: (TA=25
