Image preview - the first page of the document



>> Download czt2955_czt3055 documenatation <<

Text preview - extract from the document

               CZT2955 PNP
               CZT3055 NPN
                                                                             w w w. c e n t r a l s e m i . c o m
            SURFACE MOUNT
            COMPLEMENTARY                    DESCRIPTION:
      SILICON POWER TRANSISTORS              The CENTRAL SEMICONDUCTOR CZT2955 and
                                             CZT3055 types are surface mount epoxy molded
                                             complementary silicon transistors manufactured by the
                                             epitaxial base process, designed for surface mounted
                                             power amplifier applications up to 6.0 amps.

                                             MARKING: FULL PART NUMBER


               SOT-223 CASE


MAXIMUM RATINGS: (TA=25
