Image preview - the first page of the document



>> Download 2n6093 documenatation <<

Text preview - extract from the document

                                                                                                                       2N6093

               NPN SILICON RF POWER TRANSISTOR


                                                                           PACKAGE STYLE TO-217
DESCRIPTION:
The 2N6093 is a High Gain Linear RF
Power Amplifier Used in Class A or
Class B Applications With Individual
Ballast Emitter Resistor and Built in
Temperature Sensing Diode.

MAXIMUM RATINGS
   IC                   10 A
  VCE                   35 V
                                       O
 PDISS         83.3 W @ TC = 75 C
                    O              O                                                              1 = Emitter & Diode Cathode
 TJ             -65 C to +200 C
                                                                                                  2 = Collector
                    O              O
 TSTG           -65 C to +200 C                                                                   3 = Base
                         O                                                                        4 = Diode Anode
  JC                1.50 C/W
