Image preview - the first page of the document
mmbt4403


>> Download mmbt4403 documenatation <<

Text preview - extract from the document

                  Guilin Strong Micro-Electronics Co.,Ltd.
GM4403




MAXIMUM          RATINGS

Characteristic                           Symbol           Rating             Unit

Collector-Emitter Voltage
                                         VCEO              -40               Vdc
-
Collector-Base Voltage
                                         VCBO              -40               Vdc
-

Emitter-Base Voltage
                                         VEBO              -5.0              Vdc
-

Collector Current-Continuous
                                           Ic              -600             mAdc
-

THERMAL          CHARACTERISTICS

Characteristic                                  Symbol     Max               Unit

Total Device Dissipation                                     225             mW
FR-5 Board(1)                                     PD
TA=25 25                                                     1.8            mW/
Derate above25  25
Total Device Dissipation                                     300             mW
Alumina Substrate, (2)                            PD
TA=25 25                                                     2.4            mW/
Derate above25  25
Thermal Resistance Junction to Ambient          RJA          417             /W

Junction and Storage Temperature                TJ,Tstg           150, -55to+150


DEVICE           MARKING

GM4403=2T
GM4403=2T

                  Guilin Strong Micro-Electronics Co.,Ltd.
GM4403
ELECTRICAL        CHARACTERISTICS
   =25 unless otherwise noted  25)
(TA=25                           )
OFF    CHARACTERISTICS

 Characteristic                            Symbol     Min     Max     Unit

 Collector-Emitter Breakdown Voltage(3)
                                           V(BR)CEO    -40     --     Vdc
 -(Ic=-1.0mAdc,IB=0)
 Collector-Base Breakdown Voltage
                                           V(BR)CBO    -40     __     Vdc
 (Ic=-0.1mAdc,IE=0)
 Emitter-Base Breakdown Voltage
                                           V(BR)EBO   -5.0     --     Vdc
 (IE=-0.1mAdc,Ic=0)
 Base Cutoff Current
 (VCE=-35Vdc, VEB=-0.4Vdc)                  IBEV       --      0.1    uAdc

 Collector Cutoff Current
 (VCE=-35Vdc, VEB=-0.4Vdc)                  ICEX       --      0.1    uAdc

1. FR-5=1.0
