Image preview - the first page of the document
nds9936


>> Download nds9936 documenatation <<

Text preview - extract from the document
                                                                                                                        February 1996



     NDS9936
     Dual N-Channel Enhancement Mode Field Effect Transistor


     General Description                                                 Features

     These N-Channel enhancement mode power field effect                   5A, 30V. RDS(ON) = 0.05 @ VGS = 10V.
     transistors are produced using Fairchild's proprietary, high cell
     density, DMOS technology. This very high density process is           High density cell design for extremely low RDS(ON).
     especially tailored to minimize on-state resistance and provide
     superior switching performance. These devices are particularly        High power and current handling capability in a widely used
     suited for low voltage applications such as DC/DC conversion,         surface mount package.
     disk drive motor control, and other battery powered circuits          Dual MOSFET in surface mount package.
     where fast switching, low in-line power loss, and resistance to
     transients are needed.




________________________________________________________________________________


                                                                                     5                              4

                                                                                    6                               3

                                                                                     7                              2

                                                                                     8                              1




Absolute Maximum Ratings T A = 25
