Image preview - the first page of the document
>> Download mpsa94a documenatation <<
Text preview - extract from the document
SEMICONDUCTOR MPSA94A
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
HIGH VOLTAGE APPLICATION.
FEATURES B C
High Breakdown Voltage.
A
N DIM MILLIMETERS
E A 4.70 MAX
K
G B 4.80 MAX
C 3.70 MAX
MAXIMUM RATING (Ta=25 ) D
D 0.45
J
E 1.00
CHARACTERISTIC SYMBOL RATING UNIT F 1.27
G 0.85
Collector-Base Voltage VCBO -480 V H 0.45
H J _
14.00 + 0.50
Collector-Emitter Voltage VCEO -480 V F F K 0.55 MAX
L 2.30
Emitter-Base Voltage VEBO -6 V M 0.45 MAX
N 1.00
1 2 3
C
Collector Current IC -300 mA
L
M
1. EMITTER
Collector Power Dissipation PC 625 mW 2. BASE
3. COLLECTOR
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
TO-92
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector-Base Breakdown Voltage V(BR)CBO IC=-100 A, IE=0 -480 - - V
Collector-Emitter Breakdown Voltage V(BR)CEO IC=-1mA, IB=0 -480 - - V
Collector-Emitter Breakdown Voltage V(BR)CES IC=-100 A, IB=0 -480 - - V
Emitter-Base Breakdown Voltage V(BR)EBO IE=-10 A, IC=0 -6.0 - - V
Collector Cut off Current ICBO VCB=-400V, IE=0 - - -100 nA
Collector Cut off Current ICES VCE=-480V, IB=0 - - -1 A
Emitter Cutoff Current IEBO VEB=-4V, IC=0 - - -100 nA
VCE=-10V, IC=-1mA 40 - -
VCE=-10V, IC=-10mA 50 - 300
DC Current Gain * hFE
VCE=-10V, IC=-50mA 45 - -
VCE=-10V, IC=-100mA 40 - -
VCE(sat)1 IC=-1mA, IB=-0.1mA - - -0.35
Collector-Emitter Saturation Voltage * VCE(sat)2 IC=-20mA, IB=-2mA - - -0.5 V
VCE(sat)3 IC=-50mA, IB=-5mA - - -0.75
Base-Emitter Saturation Voltage * VBE(sat) IC=-10mA, IB=-1mA - - -0.75 V
*Pulse Test : Pulse Width 300 S, Duty Cycle 2%
2003. 12. 9 Revision No : 0 1/2
MPSA94A
h FE - IC VBE(sat) - I C
SATURATION VOLTAGE VBE(sat) (mV)
1K 10K
V CE =-10V IC =10I B
300
DC CURRENT GAIN h FE
3K
100
30 1K
10
300
3
1 100
-1 -3 -10 -30 -100 -300 -1k 1 3 10 30 100 300 1K
COLLECTOR CURRENT I C (mA) COLLECTOR CURRENT I C (mA)
VCE(sat) - I C C ob - V CB
SATURATION VOLTAGE VCE(sat) (mV)
100K 100
COLLECTOR OUTPUT CAPACITANCE
I C =10I B f=1MHz
30K IE =0
10K 30
3K
Cob(pF)
1K 10
300
100 3
30
10 1
1 3 10 30 100 300 1K 0.1 0.3 1 3 10 30 100
COLLECTOR CURRENT I C (mA) COLLECTOR BASE VOLTAGE V CB (V)
2003. 12. 9 Revision No : 0 2/2
