Image preview - the first page of the document
mpsa27


>> Download mpsa27 documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                        MPSA27
                                              TECHNICAL DATA                           EPITAXIAL PLANAR NPN TRANSISTOR


  DARLINGTON TRANSISTOR

                                                                                                   B                             C

  FEATURES
    Complementary to MPSA77.




                                                                                                                       A
                                                                                                                                      N    DIM       MILLIMETERS
                                                                                                                   E                        A         4.70 MAX
                                                                                           K
                                                                                                           G                                B         4.80 MAX
                                                                                           D                                                C         3.70 MAX




                                                                                                                       J
                                                                                                                                            D             0.45
                                                                                                                                            E             1.00
  MAXIMUM RATINGS (Ta=25                  )                                                                                                 F             1.27
                                                                                                                                            G             0.85
         CHARACTERISTIC                   SYMBOL      RATING       UNIT                                                                     H             0.45
                                                                                                       H                                    J               _
                                                                                                                                                      14.00 + 0.50
   Collector-Base Voltage                     VCBO          60       V                     F                   F                            K         0.55 MAX
                                                                                                                                            L             2.30
   Collector-Emitter Voltage                  VCES          60       V                                                                      M         0.45 MAX
                                                                                                                                            N            1.00




                                                                                                                       C
                                                                                               1   2   3
   Emitter-Base Voltage                       VEBO          10       V




                                                                                       L




                                                                                                                   M
                                                                                                                            1. EMITTER
   Collector Current                           IC           500     mA                                                      2. BASE
                                                                                                                            3. COLLECTOR
   Collector Power Dissipation                 PC           625     mW
   Junction Temperature                        Tj           150
   Storage Temperature Range                  Tstg    -55 150                                                               TO-92




  ELECTRICAL CHARACTERISTICS (Ta=25                     )
               CHARACTERISTIC                        SYMBOL               TEST CONDITION                           MIN.        TYP.        MAX.             UNIT
   Collector Cut-off Current                           ICBO       VCE=50V, IE=0                                        -          -          100             nA
   Emitter Cut-off Current                             IEBO       VEB=10V, IB=0                                        -          -          100             nA
   Collector-Emitter Breakdown Voltage               V(BR)CES     IC=100 A, IE=0                                       60         -              -            V
   Collector-Base Breakdown Voltage                  V(BR)CBO     IC=100 A, IE=0                                       60         -              -            V
                                                     hFE(1) *     VCE=5V, IC=10mA                                  10K            -              -
   DC Current Gain
                                                     hFE(2) *     VCE=5V, IC=100mA                                 10K            -              -
   Collector-Emitter Saturation Voltage              VCE(sat) *   IC=100mA, IB=0.1mA                                   -          -          1.5              V
   Base-Emitter Voltage                               VBE *       VCE=5V, IC=100mA                                     -          -              2            V
  * Pulse Test : PW 300 S, Duty Cycle 2%.




2002. 2. 20                      Revision No : 1                                                                                                                     1/2
                                MPSA27




2002. 2. 20   Revision No : 1            2/2
