Image preview - the first page of the document
bc337


>> Download bc337 documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                                         BC337
                                           TECHNICAL DATA                                           EPITAXIAL PLANAR NPN TRANSISTOR


  GENERAL PURPOSE APPLICATION.
  SWITCHING APPLICATION.
                                                                                                                B                             C

  FEATURES
    High Current : IC=800mA.




                                                                                                                                    A
    DC Current Gain : hFE=100 630 (VCE=1V, Ic=100mA).
    For Complementary with PNP type BC327.                                                                                                        N    DIM   MILLIMETERS
                                                                                                                                E                       A     4.70 MAX
                                                                                                        K
                                                                                                                        G                               B     4.80 MAX
                                                                                                        D                                               C     3.70 MAX




                                                                                                                                    J
                                                                                                                                                        D         0.45
                                                                                                                                                        E         1.00
                                                                                                                                                        F         1.27
  MAXIMUM RATING (Ta=25                )                                                                                                                G         0.85
                                                                                                                                                        H         0.45
                                                                                                                    H                                   J           _
                                                                                                                                                              14.00 + 0.50
          CHARACTERISTIC                   SYMBOL           RATING          UNIT
                                                                                                        F                   F                           K     0.55 MAX
                                                                                                                                                        L         2.30
   Collector-Base Voltage                   VCBO                50           V                                                                          M     0.45 MAX
                                                                                                                                                        N        1.00
   Collector-Emitter Voltage                VCEO                45           V




                                                                                                                                    C
                                                                                                            1   2   3




                                                                                                    L




                                                                                                                                M
   Emitter-Base Voltage                     VEBO                 5           V                                                          1. COLLECTOR
                                                                                                                                        2. BASE
   Collector Current                          IC                800         mA                                                          3. EMITTER

   Emitter Current                            IE                -800        mA
   Collector Power Dissipation               PC                 625         mW                                                          TO-92
   Junction Temperature                       Tj                150
   Storage Temperature Range                 Tstg           -55 150




  ELECTRICAL CHARACTERISTICS (Ta=25                         )
              CHARACTERISTIC                        SYMBOL                     TEST CONDITION                               MIN.           TYP.        MAX.        UNIT
   Collector Cut-off Current                         ICBO              VCB=45V, IE=0                                            -            -          100          nA
   DC Current Gain (Note)                             hFE              VCE=1V, IC=100mA                                     100              -          630
   Collector-Emitter Saturation Voltage             VCE(sat)           IC=500mA, IB=50mA                                        -            -          0.7           V
   Base-Emitter Voltage                             VBE(ON)            VCE=1V, IC=300mA                                         -            -          1.2           V
   Transition Frequency                               fT               VCE=5V, IC=10mA, f=100MHz                                -           100          -          MHz
   Collector Output Capacitance                       Cob              VCB=10V, f=1MHz, IE=0                                    -           16           -           pF
  Note : hFE Classification none:100 630,     16:100 250,              25:160 400,     40:250 630




2000. 2. 28                      Revision No : 2                                                                                                                             1/2
                                BC337




2000. 2. 28   Revision No : 2           2/2
