Image preview - the first page of the document
bc637


>> Download bc637 documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                                    BC637
                                           TECHNICAL DATA                                      EPITAXIAL PLANAR NPN TRANSISTOR


  HIGH CURRENT TRANSISTORS.

                                                                                                          B                             C

  FEATURES
    Complementary to BC638.




                                                                                                                               A
                                                                                                                                            N     DIM   MILLIMETERS
                                                                                                                          E                        A     4.70 MAX
                                                                                                  K
                                                                                                                  G                                B     4.80 MAX
                                                                                                  D                                                C     3.70 MAX
  MAXIMUM RATING (Ta=25                )




                                                                                                                               J
                                                                                                                                                   D         0.45
                                                                                                                                                   E         1.00
         CHARACTERISTIC                SYMBOL          RATING           UNIT                                                                       F         1.27
                                                                                                                                                   G         0.85
   Collector-Base Voltage                  VCBO                 60        V                                                                        H         0.45
                                                                                                              H                                    J           _
                                                                                                                                                         14.00 + 0.50
   Collector-Emitter Voltage               VCEO                 60        V                       F                   F                            K     0.55 MAX
                                                                                                                                                   L         2.30
                                                                                                                                                   M     0.45 MAX
   Emitter-Base Voltage                    VEBO                 5         V
                                                                                                                                                   N        1.00




                                                                                                                              C
                                                                                                      1   2   3




                                                                                              L
   Collector Current                        IC              500          mA




                                                                                                                          M
                                                                                                                                   1. EMITTER
   Collector Power Dissipation              PC              625          mW                                                        2. COLLECTOR
                                                                                                                                   3. BASE
   Junction Temperature                     Tj              150
   Storage Temperature                     Tstg        -55 150
                                                                                                                                   TO-92




  ELECTRICAL CHARACTERISTICS (Ta=25                         )
              CHARACTERISTIC                       SYMBOL                     TEST CONDITION                          MIN.           TYP.         MAX.        UNIT
   Collector Cut-off Current                         ICBO            VCB=30V, IE=0                                         -            -          100          nA
   Collector-Emitter Breakdown Voltage *           V(BR)CEO          IC=10mA, IB=0                                        60            -           -            V
   Collector-Base Breakdown Voltage                V(BR)CBO          IC=100 A, IE=0                                       60            -           -            V
   Emitter-Base Breakdown Voltage                  V(BR)EBO          IE=10 A, IC=0                                        5.0           -           -            V
   DC Current Gain                                   hFE             VCE=2V, IC=150mA                                     40            -          160
   Collector-Emitter Saturation Voltage            VCE(sat)          IC=500mA, IB=50mA                                     -            -          0.5           V
   Base-Emitter Voltage                              VBE             VCE=2V, IC=500mA                                      -            -          1.0           V
   Transition Frequency                               fT             VCE=2V, IC=50mA, f=100MHz                             -          200           -          MHz
   Input Capacitance                                 Cib             VEB=0.5V, IC=0, f=1MHz                                -           50           -           pF
   Collector Output Capacitance                      Cob             VCB=10V, IE=0, f=1MHz                                 -           7.0          -           pF
  * Pulse Test : Pulse Width 300 S, Duty Cycle 2.0%




2000. 10. 2                      Revision No : 0                                                                                                                        1/1
