Image preview - the first page of the document
>> Download bc807 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR BC807
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
GENERAL PURPOSE APPLICATION.
SWITCHING APPLICATION.
E
FEATURES L B L
DIM MILLIMETERS
Complementary to BC817. A _
2.93 + 0.20
B 1.30+0.20/-0.15
C 1.30 MAX
D
2 3 0.45+0.15/-0.05
D
A
G
E 2.40+0.30/-0.20
H
1 G 1.90
H 0.95
MAXIMUM RATING (Ta=25 ) J 0.13+0.10/-0.05
K 0.00 ~ 0.10
CHARACTERISTIC SYMBOL RATING UNIT L 0.55
P P
M 0.20 MIN
Collector-Base Voltage VCBO -50 V N 1.00+0.20/-0.10
N
P 7
C
J
Collector-Emitter Voltage VCEO -45 V
M
K
Emitter-Base Voltage VEBO -5 V
Collector Current IC -800 mA 1. EMITTER
2. BASE
Emitter Current IE 800 mA
3. COLLECTOR
Collector Power Dissipation PC* 350 mW
Junction Temperature Tj 150 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
