Image preview - the first page of the document



>> Download bc807w documenatation <<

Text preview - extract from the document

                                   SEMICONDUCTOR                                                                                      BC807W
                                             TECHNICAL DATA                                                 EPITAXIAL PLANAR PNP TRANSISTOR


 GENERAL PURPOSE APPLICATION.
 SWITCHING APPLICATION.

 FEATURES                                                                                                                      E
                                                                                                                      M        B       M
   Complementary to BC817W.
                                                                                                                                                       DIM     MILLIMETERS
                                                                                                                                                        A              _
                                                                                                                                                                  2.00 + 0.20
                                                                                                                                                   D
                                                                                                                          2                             B              _
                                                                                                                                                                  1.25 + 0.15




                                                                                                          A
                                                                                                                                                                       _




                                                                                                              J
                                                                                                                                                        C         0.90 + 0.10
                                                                                                                          1           3




                                                                                                                  G
                                                                                                                                                        D       0.3+0.10/-0.05
                                                                                                                                                        E              _
                                                                                                                                                                  2.10 + 0.20
 MAXIMUM RATING (Ta=25                   )                                                                                                              G             0.65
                                                                                                                                                        H       0.15+0.1/-0.06
             CHARACTERISTIC                  SYMBOL          RATING              UNIT                                                                   J             1.30
                                                                                                                                                        K         0.00~0.10
   Collector-Base Voltage                      VCBO                 -50                V                                                                L             0.70




                                                                                                              C
                                                                                                                                               H




                                                                                                                  L
                                                                                                                                                        M             0.42
   Collector-Emitter Voltage                   VCEO                 -45                V                                                                N          0.10 MIN
                                                                                                                      N                   N
                                                                                                                              K

   Emitter-Base Voltage                        VEBO                  -5                V
   Collector Current                            IC                  -500         mA                                   1. EMITTER

   Emitter Current                              IE                  500          mA                                   2. BASE
                                                                                                                      3. COLLECTOR
   Collector Power Dissipation                  PC                  100          mW
   Junction Temperature                         Tj                  150
