Image preview - the first page of the document
>> Download bc859_bc860 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR BC859/860
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
GENERAL PURPOSE APPLICATION.
SWITCHING APPLICATION.
E
For Complementary with NPN Type BC849/850 L B L
DIM MILLIMETERS
A _
2.93 + 0.20
B 1.30+0.20/-0.15
C 1.30 MAX
D
MAXIMUM RATING (Ta=25 ) 2 3 D 0.45+0.15/-0.05
A
G
E 2.40+0.30/-0.20
H
CHARACTERISTIC SYMBOL RATING UNIT 1 G 1.90
H 0.95
Collector-Base BC859 -30 J 0.13+0.10/-0.05
VCBO V K 0.00 ~ 0.10
Voltage BC860 -50 L 0.55
P P
M 0.20 MIN
Collector-Emitter BC859 -30 N 1.00+0.20/-0.10
VCEO V
N
C
P 7
J
Voltage BC860 -45
M
K
Emitter-Base Voltage VEBO -5 V
Collector Current IC -100 mA
1. EMITTER
Collector Power Dissipation PC * 350 mW 2. BASE
3. COLLECTOR
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
PC* : Package Mounted On 99.5% Alumina 10 8 0.6mm.
SOT-23
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector-Emitter BC859 -30 - -
V(BR)CEO IC=-10mA, IB=0 V
Breakdown Voltage BC860 -45 - -
Collector-Base BC859 -30 - -
V(BR)CBO IC=-10 A, IE=0 V
Breakdown Voltage BC860 -50 - -
Emitter-Base Breakdown Voltage V(BR)EBO IE=-10 A, IC=0 -5 - - V
Collector Cut-off Current ICBO VCB=-30V, IE=0 - - -15 nA
DC Current Gain hFE IC=-2mA, VCE=-5V 125 - 475
VBE(ON) 1 IC=-2mA, VCE=-5V -0.6 -0.65 -0.75
Base-Emitter Voltage V
VBE(ON) 2 IC=-10mA, VCE=-5V - - -0.82
VCE(sat) 1 IC=-10mA, IB=-0.5mA - -0.075 -0.3
Collector-Emitter Saturation Voltage V
VCE(sat) 2 IC=-100mA, IB=-5mA - -0.25 -0.65
VBE(sat) 1 IC=-10mA, IB=-0.5mA - -0.7 -
Base-Emitter Saturation Voltage V
VBE(sat) 2 IC=-100mA, IB=-5mA - -0.85 -
Transition Frequency fT IC=-10mA, VCE=-5V, f=100MHz - 150 MHz
Collector Output Capacitance Cob VCB=-10V, IE=0, f=1MHz - 4.5 - pF
IC=-200 A, VCE=-5V
Noise Figure NF - - 4.0 dB
Rg=10k , f=1kHz
Note : hFE Classification A:125 250, B:220 475
Marking
MARK SPEC Lot No.
TYPE BC859A BC859B BC860A BC860B
Type Name
MARK 4A 4B 4E 4G
1998. 6. 15 Revision No : 2 1/2
BC859/860
I C - V CE I C - V BE
-50 -100
COLLECTOR CURRENT I C (mA)
COLLECTOR CURRENT I C (mA)
-50 V CE =-5V
