Image preview - the first page of the document
>> Download bcw71_bcw72_bcv71_bcv72 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR BCV71/72, BCW71/72
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
LOW LEVEL AUDIO-AMPLIFIER AND SWITCHING.
E
FEATURES L B L
DIM MILLIMETERS
Super Mini Packaged Transistor for Hybrid Circuits. A _
2.93 + 0.20
For Complementary with PNP Type BCW69/70/89. B 1.30+0.20/-0.15
C 1.30 MAX
D
2 3 0.45+0.15/-0.05
D
A
G
E 2.40+0.30/-0.20
H
1 G 1.90
H 0.95
J 0.13+0.10/-0.05
MAXIMUM RATING (Ta=25 ) K 0.00 ~ 0.10
L 0.55
P P
M 0.20 MIN
CHARACTERISTIC SYMBOL RATING UNIT
N 1.00+0.20/-0.10
N
C
P 7
J
Collector-Base BCW71/72 50
VCBO V
K
Voltage M
BCV71/72 60
Collector-Emitter BCW71/72 45 1. EMITTER
VCEO V
Voltage BCV71/72 60 2. BASE
3. COLLECTOR
Emitter-Base Voltage VEBO 5 V
Collector Current IC 100 mA
Emitter Current IE -100 mA SOT-23
Collector Power Dissipation PC 200 mW
Junction Temperature Tj 150
Storage Temperature Range Tstg -65 150
* : Package Mounted On 99.9% Alumina 10 8 0.6mm.
MARK SPEC
TYPE MARK
Marking
BCW71 K1
Lot No.
BCW72 K2
BCV71 K7 Type Name
BCV72 K8
2002. 6. 18 Revision No : 2 1/2
BCV71/72, BCW71/72
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector-Emitter BCW71/72 45 - -
V(BR)CEO IC=2mA, IB=0 V
Breakdown Voltage BCV71/72 60 - -
Collector-Base BCW71/72 50 - -
V(BR)CBO IC=10 A, IE=0 V
Breakdown Voltage BCV71/72 60 - -
Emitter-Base Breakdown Voltage V(BR)EBO IE=10 A, IC=0 5.0 - - V
VCB=20V, IE=0 - - 100 nA
Collector Cut-off Current ICBO
Ta=100 , VCB=20V, IE=0 - - 10 A
BCV71/BCW71 - 100 -
VCE=5V, IC=10 A
BCV72/BCW72 - 160 -
DC Current Gain hFE
BCV71/BCW71 110 - 220
VCE=5V, IC=2mA
BCV72/BCW72 200 - 450
Base-Emitter Voltage VBE(ON) VCE=5V, IC=2mA 550 - 700 mV
IC=10mA, IB=0.5mA - 750 -
Base-Emitter Saturation Voltage VBE(sat) mV
IC=50mA, IB=2.5mA - 870 -
IC=10mA, IB=0.5mA - - 250
Collector-Emitter Saturation Voltage VCE(sat) mV
IC=50mA, IB=2.5mA - 230 -
Transition Frequency fT IC=10mA, VCE=5V, f=100MHz - 300 - MHz
Collector Output Capacitance Cob VCB=10V, IE=0, f=1MHz - - 4.0 pF
IC=0.2mA, VCE=5V, f=200Hz
Noise Figure NF - - 10 dB
Rg=2k , f=1kHz
2002. 6. 18 Revision No : 2 2/2
