Image preview - the first page of the document



>> Download kta1532u documenatation <<

Text preview - extract from the document

                                     SEMICONDUCTOR                                                                                KTA1532U
                                             TECHNICAL DATA                                                 EPITAXIAL PLANAR PNP TRANSISTOR


 LOW FREQUENCY AMPLIFIER DRIVER

 FEATURES
                                                                                                                                  E
   A Collector Current is large.                                                                                         M        B         M

   Collector Saturation Voltage is low.                                                                                                                    DIM    MILLIMETERS
                                                                                                                                                            A             _
                                                                                                                                                                     2.00 + 0.20
                                                                                                                                                       D
   VCE(sat)    -200mV at IC=500mA, ID=-25mA.                                                                                2                               B             _
                                                                                                                                                                    1.25 + 0.15
                                                                                                                                                                          _




                                                                                                            A
                                                                                                                                                            C        0.90 + 0.10




                                                                                                                J
                                                                                                                            1              3




                                                                                                                    G
                                                                                                                                                            D     0.3+0.10/-0.05
                                                                                                                                                            E             _
                                                                                                                                                                    2.10 + 0.20
                                                                                                                                                            G          0.65
                                                                                                                                                            H     0.15+0.1/-0.06
                                                                                                                                                            J             1.30
 MAXIMUM RATING (Ta=25                   )                                                                                                                  K          0.00-0.10
                                                                                                                                                            L             0.70
        CHARACTERISTIC                   SYMBOL              RATING              UNIT




                                                                                                            C
                                                                                                                                                   H                        _




                                                                                                                    L
                                                                                                                                                            M          0.42 + 0.10
   Collector-Base Voltage                    VCBO                -15                   V                                                                    N          0.10 MIN
                                                                                                                        N                      N
                                                                                                                                K
   Collector-Emitter Voltage                 VCEO                -12                   V
   Emitter-Base Voltage                      VEBO                    -6                V                                1. EMITTER

                             DC               IC                 -1.5                                                   2. BASE
   Collector Current                                                                   A                                3. COLLECTOR
                             Pulse           ICP                     -3
   Collector Power Dissipation               PC*                 0.2                   W
   Junction Temperature                       Tj                 150
