Image preview - the first page of the document
>> Download kta1807d_l documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTA1807D/L
TECHNICAL DATA TRIPLE DIFFUSED PNP TRANSISTOR
HIGH VOLTAGE SWITCHING.
POWER SUPPLY SWITCHING FOR TELEPHONES.
A
FEATURES I
C J
High Voltage : VCEO=-600V.
DIM MILLIMETERS
High Speed Switching Time.
D
A _
6.60 + 0.2
B _
6.10 + 0.2
: tf 1.0 s (IC=-0.5A) C _
5.0 + 0.2
_
B
Low Collector Emitter Saturation Voltage. D 1.10 + 0.2
_
E 2.70 + 0.2
: VCE(sat)=-0.28V (IC=-0.3A, IB=-60mA) F _
2.30 + 0.1
M
H 1.00 MAX
Q
Wide Safe Operating Area (SOA).
K
E
I _
2.30 + 0.2
O
J _
0.5 + 0.1
H P K _
2.00 + 0.20
L _
0.50 + 0.10
F F L _
M 0.91+ 0.10
O _
0.90 + 0.1
1 2 3 _
P 1.00 + 0.10
MAXIMUM RATING (Ta=25 ) Q 0.95 MAX
CHARACTERISTIC SYMBOL RATING UNIT 1. BASE
2. COLLECTOR
Collector-Base Voltage VCBO -600 V 3. EMITTER
Collector-Emitter Voltage VCEO -600 V
Emitter-Base Voltag VEBO -7 V
IC
DPAK
DC -1.0
Collector Current A
Pulse * ICP -2.0
Collector Power Dissipation PC 1.0 W
Junction Temperature Tj 150 A
C
I
J
Storage Temperature Range Tstg -55 150 D
* PW 10ms, Duty Cycle 50%.
B
DIM MILLIMETERS
A _
6.60 + 0.2
B _
6.10 + 0.2
_
Q
5.0 + 0.2
K
C
D _
1.10 + 0.2
H P
E _
9.50 + 0.6
E
G F _
2.30 + 0.1
G _
0.76 + 0.1
H 1.0 MAX
I _
2.30 + 0.2
J _
0.5 + 0.1
F F L _
K 2.0 + 0.2
L _
0.50 + 0.1
P _
1.0 + 0.1
1 2 3 Q 0.90 MAX
1. BASE
2. COLLECTOR
3. EMITTER
IPAK
2003. 3. 27 Revision No : 2 1/4
KTA1807D/L
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=-600V, IE=0 - - -10 A
Emitter Cut-off Current IEBO VEB=-7.0V, IC=0 - - -10 A
hFE (1) (Note) VCE=-5.0V, IC=-0.1A 30 - 120
DC Current Gain
hFE (2) VCE=-5.0V, IC=-0.5A 5 - -
Collector-Emitter Saturation Voltage VCE(sat) IC=-0.3A, IB=-60mA - -0.28 -1.0 V
Base-Emitter Saturation Voltage VBE(sat) IC=-0.3A, IB=-60mA - -0.85 -1.2 V
Gain-Bandwidth Product fT VCE=-10V, IE=50mA - 28 - MHz
Collector Output Capacitance Cob VCB=-10V, IE=0, f=1MHz - 42 - pF
Turn On Time ton - 0.1 0.5
Switching IC=-0.5A, RL=500 ,
Storage Time tstg - 3.5 5.0 s
Time IB1=-IB2=-0.1A, VCC=-250V
Fall Time tf - 0.08 0.5
Note : hFE Classification O:30~80, Y:60~120.
2003. 3. 27 Revision No : 2 2/4
KTA1807D/L
REVERSE BIAS I C - V CE
SAFE OPERATING AREA
-1.0 -100
-1.8mA
COLLECTOR CURRENT I C (mA)
A
COLLECTOR CURRENT I C (A)
.0m
-1.6mA
-2
-0.8 -80
-1.4mA
-0.6 -60 -1.2mA
-1.0mA
-0.4 VCEO (SUS) -40 -0.8mA
-0.6mA
-0.2 -20 -0.4mA
I B =-0.2mA
0 0
0 -200 -400 -600 -800 -1K 0 -2 -4 -6 -8 -10
COLLECTOR-EMITTER VOLTAGE V CE (V) COLLECTOR-EMITTER VOLTAGE VCE (V)
I C - V BE h FE - I C
-1.0 1K
V CE =-5V V CE =-5V
COLLECTOR CURRENT I C (A)
300
DC CURRENT GAIN h FE
-0.3
100
-0.1
30
-0.03
10
-0.01 3
-0.003 1
0 -0.2 -0.4 -0.6 -0.8 -1.0 -1.2 -1.4 -1.6 -0.002 -0.005 -0.01 -0.02 -0.05 -0.1 -0.2 -0.5 -1 -2
BASE-EMITTER VOLTAGE V BE (V) COLLECTOR CURRENT I C (A)
COLLECTOR SATURATION VOLTAGE VCE(sat) (V)
VCE(sat) , VBE(sat) - I C t - IC
BASE SATURATION VOLTAGE VBE(sat) (V)
-3 10
I C / I B =5 I C / I B =5
VCE =-250V
