Image preview - the first page of the document
>> Download kta1266 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTA1266
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
GENERAL PURPOSE APPLICATION.
SWITCHING APPLICATION.
B C
FEATURES
Excellent hFE Linearity
A
: hFE(2)=80(Typ.) at VCE=-6V, IC=-150mA
: hFE(IC=0.1mA)/hFE(IC=2mA)=0.95(Typ.). N DIM MILLIMETERS
E A 4.70 MAX
K
Low Noise : NF=1dB(Typ.). at f=1kHz. G B 4.80 MAX
D C 3.70 MAX
Complementary to KTC3198. D 0.45
J
E 1.00
F 1.27
G 0.85
H 0.45
H J _
14.00 + 0.50
F F K 0.55 MAX
MAXIMUM RATING (Ta=25 ) L 2.30
M 0.45 MAX
CHARACTERISTIC SYMBOL RATING UNIT N 1.00
1 2 3
C
L
M
Collector-Base Voltage VCBO -50 V
1. EMITTER
Collector-Emitter Voltage VCEO -50 V 2. COLLECTOR
3. BASE
Emitter-Base Voltage VEBO -5 V
Collector Current IC -150 mA
TO-92
Base Current IB -50 mA
Collector Power Dissipation PC 625 mW
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=-50V, IE=0 - - -0.1 A
Emitter Cut-off Current IEBO VEB=-5V, IC=0 - - -0.1 A
hFE(1) (Note) VCE=-6V, IC=-2mA 70 - 400
DC Current Gain
hFE(2) VCE=-6V, IC=-150mA 25 - -
Collector-Emitter Saturation Voltage VCE(sat) IC=-100mA, IB=-10mA - -0.1 -0.3 V
Base-Emitter Saturation Voltage VBE(sat) IC=-100mA, IB=-10mA - - -1.1 V
Transition Frequency fT VCE=-10V, IC=-1mA 80 - - MHz
Collector Output Capacitance Cob VCB=-10V, IE=0, f=1MHz - 4.0 7.0 pF
Base Intrinsic Resistance rbb' VCB=-10V, IE=1mA, f=30MHz - 30 -
Noise Figure NF VCE=-6V, IC=-0.1mA, Rg=10k , f=1kHz - 1.0 10 dB
Note : hFE(1) Classification O:70 140, Y:120 240, GR:200 400
2002. 9. 12 Revision No : 2 1/2
KTA1266
I C - VCE h FE - I C
-240 3k
COMMON EMITTER COMMON EMITTER
COLLECTOR CURRENT I C (mA)
-2.0 Ta=25 C
-200
DC CURRENT GAIN h FE
-1.5 1k
-160
-1.0 500
Ta=100 C V
-120 300 CE
=-
6V
-0.5 Ta=25 C
-80 Ta=-25 C VC
100 E =-
1V
IB =-0.2mA
-40
50
0
0 30
0 -1 -2 -3 -4 -5 -6 -7 -0.1 -0.3 -1 -3 -10 -30 -100 -300
COLLECTOR-EMITTER VOLTAGE VCE (V) COLLECTOR CURRENT I C (mA)
VCE(sat) - I C fT - IC
-1k 3k
COLLECTOR-EMITTER SATURATION
TRANSITION FREQUENCY f T (MHz)
COMMON EMITTER COMMON EMITTER
-500 I C /I B =10 VCE =-10V
Ta=25 C
VOLTAGE VCE(sat) (mV)
-300 1k
500
-100 300
C
00
-50 =1
Ta
-30 Ta=25 C 100
Ta=-25 C
50
-10 30
-0.1 -0.3 -1 -3 -10 -30 -100 -300 -0.1 -0.3 -1 -3 -10 -30 -100 -300
COLLECTOR CURRENT I C (mA) COLLECTOR CURRENT I C (mA)
I B - VBE Pc - Ta
-1k 700
COLLECTOR POWER DISSIPATION
COMMON EMITTER
-300 VCE =-6V 600
BASE CURRENT I B (◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
