Image preview - the first page of the document
>> Download kta1275 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTA1275
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
COLOR TV VERT. DEFELECTION OUTPUT APPLICATION.
COLOR TV CLASS B SOUND OUTPUT APPLICATION.
B D
FEATURES
High Voltage : VCEO=-160V.
A
Large Continuous Collector Current Capability. P DIM MILLIMETERS
DEPTH:0.2 A 7.20 MAX
Complementary to KTC3228. C
B 5.20 MAX
C 0.60 MAX
G
S
Q D 2.50 MAX
K E 1.15 MAX
F 1.27
J
R
G 1.70 MAX
F F H 0.55 MAX
MAXIMUM RATING (Ta=25 ) J _
14.00 + 0.50
K 0.35 MIN
H H H
CHARACTERISTIC SYMBOL RATING UNIT L _
0.75 + 0.10
M E M M 4
Collector-Base Voltage VCBO -160 V N 25
O 1.25
D
1 2 3 L
O
Collector-Emitter Voltage VCEO -160 V H P 1.50
N N Q 0.10 MAX
_
Emitter-Base Voltage VEBO -6 V 1. EMITTER
R 12.50 + 0.50
S 1.00
IC 2. COLLECTOR
Collector Current -1 A
3. BASE
Base Current IB -0.5 A
Collector Power Dissipation PC 1 W TO-92L
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=-150V, IE=0 - - -1.0 A
Emitter Cut-off Current IEBO VEB=-6V, IC=0 - - -1.0 A
Collector-Emitter Breakdown Voltage V(BR)CEO IC=-10mA, IB=0 -160 - - V
DC Current Gain hFE (Note) VCE=-5V, IC=-200mA 60 - 320
Collector-Emitter Saturation Voltage VCE(sat) IC=-500mA, IB=-50mA - - -1.5 V
Base-Emitter Saturation Voltage VBE(sat) IC=-500mA, IB=-50mA - - -1.2 V
Base-Emitter Voltage VBE VCE=-5V, IC=-5mA -0.45 - -0.75 V
Transition Frequency fT VCE=-5V, IC=-200mA 15 50 - MHz
Collector Output Capacitance Cob VCB=-10V, IE=0, f=1MHz - - 35 pF
Note : hFE Classification R:60 120 0:100 200, Y:160 320
2007. 12. 20 Revision No : 3 1/3
KTA1275
2007. 12. 20 Revision No : 3 2/3
KTA1275
2007. 12. 20 Revision No : 3 3/3
