Image preview - the first page of the document
kta2013f


>> Download kta2013f documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                        KTA2013F
                                           TECHNICAL DATA                                         EPITAXIAL PLANAR PNP TRANSISTOR


  GENERAL PURPOSE APPLICATION.
  SWITCHING APPLICATION.

  FEATURES
                                                                                                                           E
    Excellent hFE Linearity
                                                                                                                           B
      : hFE(0.1mA)/hFE(2mA)=0.95(Typ.).
    High hFE : hFE=120~400.
    Complementary to KTC4074F.                                                                                2                              DIM       MILLIMETERS




                                                                                              A
                                                                                                  G




                                                                                                                                        D
                                                                                                                                              A                _
                                                                                                                                                           0.6 + 0.05
    Thin Fine Pitch Small Package.                                                                                                3                            _




                                                                                                          K
                                                                                                                                              B            0.8 + 0.05
                                                                                                              1                               C        0.38+0.02/-0.04
                                                                                                                                              D                _
                                                                                                                                                           0.2 + 0.05
                                                                                                                                              E                _
                                                                                                                                                           1.0 + 0.05
                                                                                                                                              G                _
                                                                                                                                                          0.35+ 0.05
                                                                                                                                              J                _
                                                                                                                                                           0.1 + 0.05
                                                                                                                                                               _
  MAXIMUM RATING (Ta=25                )                                                                                                      K           0.15 + 0.05




                                                                                                      C
              CHARACTERISTIC               SYMBOL                 RATING     UNIT




                                                                                                                                        J
  Collector-Base Voltage                     VCBO                   -20        V
                                                                                                                  1. EMITTER
  Collector-Emitter Voltage                  VCEO                   -20        V                                  2. BASE

  Emitter-Base Voltage                       VEBO                   -5         V                                  3. COLLECTOR


  Collector Current                            IC                  -150       mA
                                                                                                                               TFSM
  Base Current                                 IB                   -30       mA
  Collector Power Dissipation                  PC                   50       mW
  Junction Temperature                         Tj                   150
  Storage Temperature Range                   Tstg                -55 150


                                                                                                          Marking                       Type Name




                                                                                                                        F                   h FE Rank




  ELECTRICAL CHARACTERISTICS (Ta=25                           )
              CHARACTERISTIC                  SYMBOL                         TEST CONDITION                         MIN.         TYP.        MAX.              UNIT
  Collector Cut-off Current                         ICBO            VCB=-20V, IE=0                                     -          -           -0.1                A
  Emitter Cut-off Current                           IEBO            VEB=-5V, IC=0                                      -          -           -0.1                A
  DC Current Gain                             hFE (Note)            VCE=-5V, IC=-2mA                                 120          -           400
  Collector-Emitter Saturation Voltage             VCE(sat)         IC=-100mA, IB=-10mA                                -         -0.1         -0.3               V
  Transition Frequency                               fT             VCE=-10V, IC=-1mA                                 80          -                -           MHz
  Collector Output Capacitance                       Cob            VCB=-10V, IE=0, f=1MHz                             -          4            7                 pF
  Note : hFE Classification Y(4):120 240, GR(6):200 400




2005. 4. 21                      Revision No : 1                                                                                                                         1/3
                                KTA2013F




2005. 4. 21   Revision No : 1              2/3
                                KTA2013F




2005. 4. 21   Revision No : 1              3/3
