Image preview - the first page of the document
kta2015


>> Download kta2015 documenatation <<

Text preview - extract from the document
                                    SEMICONDUCTOR                                                                                 KTA2015
                                             TECHNICAL DATA                                             EPITAXIAL PLANAR PNP TRANSISTOR


  GENERAL PURPOSE APPLICATION.
  SWITCHING APPLICATION.

                                                                                                                              E
  FEATURES                                                                                                           M        B    M

    Excellent hFE Linearity                                                                                                                             DIM       MILLIMETERS
                                                                                                                                                         A               _
                                                                                                                                                                    2.00 + 0.20
                                                                                                                                                    D
        : hFE(2)=25(Min.) at VCE=-6V, IC=-400mA.                                                                        2                               B                _
                                                                                                                                                                    1.25 + 0.15
                                                                                                                                                                         _




                                                                                                        A
                                                                                                                                                                    0.90 + 0.10




                                                                                                            J
                                                                                                                                                        C
    Complementary to KTC4076.                                                                                           1          3




                                                                                                                G
                                                                                                                                                        D         0.3+0.10/-0.05
                                                                                                                                                        E                _
                                                                                                                                                                    2.10 + 0.20
                                                                                                                                                        G              0.65
                                                                                                                                                        H         0.15+0.1/-0.06
                                                                                                                                                        J              1.30
                                                                                                                                                        K           0.00-0.10
  MAXIMUM RATING (Ta=25                  )                                                                                                              L              0.70




                                                                                                            C
                                                                                                                                                H                        _




                                                                                                                L
                                                                                                                                                        M           0.42 + 0.10
          CHARACTERISTIC                     SYMBOL          RATING              UNIT                               N                  N
                                                                                                                                                        N            0.10 MIN
                                                                                                                             K
   Collector-Base Voltage                     VCBO                -35                  V
   Collector-Emitter Voltage                  VCEO                -30                  V                            1. EMITTER
                                                                                                                    2. BASE
   Emitter-Base Voltage                       VEBO                   -5                V
                                                                                                                    3. COLLECTOR
   Collector Current                           IC                 -500           mA
   Base Current                                IB                 -50            mA
   Collector Power Dissipation                 PC                 100            mW                                                    USM
   Junction Temperature                        Tj                 150
