Image preview - the first page of the document
ktc2874


>> Download ktc2874 documenatation <<

Text preview - extract from the document
                                     SEMICONDUCTOR                                                                           KTC2874
                                                                                                             SILICON NPN TRANSISTOR
                                            TECHNICAL DATA                                                   EPITAXIAL PLANAR TYPE

  FOR MUTING AND SWITCHING APPLICATION.

  FEATURES                                                                                                   B                        C

    High Emitter-Base Voltage : VEBO=25V(Min.)
    High Reverse hFE




                                                                                                                             A
       : Reverse hFE=150(Typ.) (VCE=-2V, IC=-4mA)
    Low on Resistance : RON=1 (Typ.), (IB=5mA)                                                                                                  DIM   MILLIMETERS
                                                                                                    D                                            A       4.7 MAX
                                                                                                                                                 B       5.1 MAX




                                                                                                                     G
                                                                                                                     E
                                                                                                    d                                            C       4.1 MAX




                                                                                                                             L
                                                                                                                                                 d          0.45
                                                                                                                                                 D      0.55 MAX
                                                                                                                                                 E           0.8
  MAXIMUM RATING (Ta=25                 )                                                                                                        G           1.8
                                                                                                                                                 L      12.7 MIN
              CHARACTERISTIC                 SYMBOL         RATING        UNIT                                                                   P          1.27
                                                                                                   P                 P                           T          0.45
   Collector-Base Voltage                     VCBO            50              V
   Collector-Emitter Voltage                  VCEO            20              V                          1   2   3




                                                                                                                     T
                                                                                                                                 1. EMITTER
   Emitter-Base Voltage                       VEBO            25              V                                                  2. COLLECTOR
                                                                                                                                 3. BASE
   Collector Current                               IC         300         mA
   Base Current                                    IB         60          mA
   Collector Power Dissipation                     PC         625         mW                                                     TO-92
   Junction Temperature                            Tj         150
   Storage Temperature Range                   Tstg         -55 150




  ELECTRICAL CHARACTERISTICS (Ta=25                     )
              CHARACTERISTIC                 SYMBOL                   TEST CONDITION                                 MIN.          TYP.         MAX.       UNIT
   Collector Cut-off Current                  ICBO       VCB=50V, IE=0                                                   -           -           0.1          A
   Emitter Cut-off Current                    IEBO       VEB=25V, IC=0                                                   -           -           0.1          A
   DC Current Gain (Note)                     hFE *      VCE=2V, IC=4mA                                              200             -          1200
   Collector-Emitter Saturation Voltage      VCE(sat)    IC=30mA, IB=3mA                                                 -         0.042         0.1          V
   Base-Emitter Voltage                       VBE        VCE=2V, IC=4mA                                                  -          0.61          -           V
   Transition Frequency                        fT        VCE=6V, IC=4mA                                                  -           30           -         MHz
   Collector Output Capacitance                Cob       VCB=10V, IE=0, f=1MHz                                           -          4.8           7          pF
                                                                                                       OUTPUT
                         Turn-on Time          tON                                                                       -          160           -
                                                                      INPUT       4k
   Switching
                                                                                                        1k




                                                        10V
                         Storage Time          tstg                                                                      -          500           -          nS
   Time
                                                                                           3k
                                                                          50




                                                              1
